Technical Data for The BMW 3 Series
Touring M Models.
| 1 | |
|---|---|
Fuel type | Petrol – 48 Volt Mild-Hybrid |
Power in kW (hp) | 275 (374) |
Torque in Nm | 500 |
Transmission | 8-speed, automatic |
Drivetrain | All-wheel drive |
| 1 | |
|---|---|
Cylinders | 6 |
Displacement in cm³ | 2,998 |
Nominal power in kW (hp)/1/min | 275 (374) / 5,500 - 6,500 |
Nominal torque in Nm/1/min | 500 / 1,900 - 5,000 |
(Nominal) power/30-minutes-power in kW (hp) | 8 (11) / - |
|---|---|
(Nominal) torque in Nm | 25 |
Acceleration 0–100 km/h in s | 4.6 |
|---|---|
Top speed in km/h | 250 |
| 1 , 2 | |
|---|---|
Fuel consumption, combined WLTP in l/100 km | 8.1 - 8.8 |
CO2 emissions, combined WLTP in g/km | 182 - 198 |
| 3 | |
|---|---|
Battery capacity in kWh | 0.4 |
4,714 mm | |
1,827 mm | |
1,440 mm | |
Length in mm | 4,714 |
Width in mm | 1,827 |
Height in mm | 1,440 |
Width incl. mirrors (driver / passenger side) in mm | 2,068 |
Vehicle curb weight in kg 4 | 1,870 |
Permissible gross weight in kg | 2,390 |
Payload in kg | 595 |
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg 5 | 1,800 / 75 |
Luggage capacity in l | 500 - 1,510 |
Tank capacity in l | 59 |
| 1 | |
|---|---|
Fuel type | Petrol |
Power in kW (hp) | 390 (530) |
Torque in Nm | 650 |
Transmission | 8-speed, automatic |
Drivetrain | All-wheel drive |
| 1 | |
|---|---|
Cylinders | 6 |
Displacement in cm³ | 2,993 |
Nominal power in kW (hp)/1/min | 390 (530) / 6,250 |
Nominal torque in Nm/1/min | 650 / 2,750 - 5,730 |
Acceleration 0–100 km/h in s | 3.6 |
|---|---|
Top speed in km/h | 250 |
| 1 , 2 | |
|---|---|
Fuel consumption, combined WLTP in l/100 km | 10.4–10.3 |
CO2 emissions, combined WLTP in g/km | 235–233 |
Pass-by noise in dB(A) | 72 |
Stationary noise level in dB(A) / 1/min | 89/3,750 |
4,801 mm | |
1,903 mm | |
1,446 mm | |
Length in mm | 4,801 |
Width in mm | 1,903 |
Height in mm | 1,446 |
Width incl. mirrors (driver / passenger side) in mm | 2,068 |
Wheelbase in mm | 2,857 |
Vehicle curb weight in kg 4 | 1,940 |
Permissible gross weight in kg | 2,370 |
Payload in kg | 505 |
Luggage capacity in l | 500 - 1,510 |
Tank capacity in l | 59 |
| 1 | |
|---|---|
Fuel type | Petrol |
Power in kW (hp) | 405 (551) |
Torque in Nm | 650 |
Transmission | 8-speed, automatic |
Drivetrain | All-wheel drive |
| 1 | |
|---|---|
Cylinders | 6 |
Displacement in cm³ | 2,993 |
Nominal power in kW (hp)/1/min | 405 (551)/6,250 |
Nominal torque in Nm/1/min | 650/2,750–5,950 |
Acceleration 0–100 km/h in s | 3.5 |
|---|---|
Top speed in km/h | 300 |
| 1 , 2 | |
|---|---|
Fuel consumption, combined WLTP in l/100 km | 10.5 |
CO2 emissions, combined WLTP in g/km | 238 |
Pass-by noise in dB(A) | 71 |
Stationary noise level in dB(A) / 1/min | 93/3,750 |
4,796 mm | |
1,918 mm | |
1,447 mm | |
Length in mm | 4,796 |
Width in mm | 1,918 |
Height in mm | 1,447 |
Width incl. mirrors (driver / passenger side) in mm | 2,068 |
Wheelbase in mm | 2,857 |
Vehicle curb weight in kg 4 | 1,925 |
Permissible gross weight in kg | 2,330 |
Payload in kg | 480 |
Luggage capacity in l | 500–1,510 |
Tank capacity in l | 59 |
| 1 | |
|---|---|
Fuel type | Petrol |
Power in kW (hp) | 375 (510) |
Torque in Nm | 650 |
Transmission | 8-speed, automatic |
Drivetrain | All-wheel drive |
| 1 | |
|---|---|
Cylinders | 6 |
Displacement in cm³ | 2,993 |
Nominal power in kW (hp)/1/min | 375 (510) / 6,250 |
Nominal torque in Nm/1/min | 650 / 2,750 - 5,500 |
Acceleration 0–100 km/h in s | 3.6 |
|---|---|
Top speed in km/h | 250 |
| 1 , 2 | |
|---|---|
Fuel consumption, combined WLTP in l/100 km | 10.3 - 10.4 |
CO2 emissions, combined WLTP in g/km | 234 - 235 |
4,801 mm | |
1,903 mm | |
1,446 mm | |
Length in mm | 4,801 |
Width in mm | 1,903 |
Height in mm | 1,446 |
Width incl. mirrors (driver / passenger side) in mm | 2,068 (1,040 / 1,028) |
Wheelbase in mm | 2,857 |
Vehicle curb weight in kg 4 | 1,940 |
Permissible gross weight in kg | 2,370 |
Payload in kg | 505 |
Luggage capacity in l | 500 - 1,510 |
Tank capacity in l | 59 |
Energy consumption and CO2 emissions.
BMW M3 CS: Energy consumption, combined WLTP in l/100 km: 10.5; CO₂ emissions, combined WLTP in g/km: 238
BMW M3 Competition M xDrive: Energy consumption, combined WLTP in l/100 km: 10.4–10.3; CO2 emissions, combined WLTP in g/km: 235–233
BMW M340i xDrive Touring¹: Energy consumption, combined WLTP in l/100 km: 8.1 - 8.8; CO₂ emissions, combined WLTP in g/km: 182 - 198
¹ Vehicle height with serial components 1,456 mm.
