BMW 3 Series Sedan (G20), technical data

THE 3

THE BMW 3 SERIES SEDAN: ENGINES & TECHNICAL DATA

Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 3 Series Sedan.

Read more
THE 3THE BMW 3 SERIES SEDAN: ENGINES & TECHNICAL DATA

TECHNICAL DATA OF THE BMW 3 SERIES

Select model

Weight

Unladen weight EU in kg 1,580-1,545
Max. permissible weight in kg 2,060
Permitted load in kg 555-590
Permitted axle load front/rear in kg 985/1,160
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 190 (258)/5,000-6,500
Engine torque (Nm) at 1/min 400/1,550-4,400
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 5.9-5.8
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 7.9
Extra-urban in l/100 km 5.8
Combined in l/100 km 6.6
CO2 combined emissions in g/km 150
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (PS) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (PS) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,545 [1,565]
Max. permissible weight in kg 2,050 [2,050]
Permitted load in kg 580 [560]
Permitted axle load front/rear in kg 965/1,160 [965/1,150]
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,300
Trailer load 12% (braked) in kg 1,300

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 115 (156)/4,500-6,500
Engine torque (Nm) at 1/min 250/1,300-4,300
Compression ratio : 1 11.0

Performance

Top speed in km/h 223 [223]
Acceleration 0–100 km/h in s 8.9 [8.4]
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 9.4 [7.4]
Extra-urban in l/100 km 6.0 [5.6]
Combined in l/100 km 7.3 [6.3]
CO2 combined emissions in g/km 166 [143]
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 58-59

Wheels

Tyre dimensions front 205/60 R16 96 W XL
Tyre dimensions rear 205/60 R16 96 W XL
Wheel dimensions and material front 6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear 6.5 J x 16 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (PS) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (PS) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,570
Max. permissible weight in kg 2,050
Permitted load in kg 555
Permitted axle load front/rear in kg 965/1,150
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,600
Trailer load 12% (braked) in kg 1,600

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 235
Acceleration 0–100 km/h in s 7.1
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 7.4
Extra-urban in l/100 km 5.6
Combined in l/100 km 6.3
CO2 combined emissions in g/km 144
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 205/60 R16 96 W XL
Tyre dimensions rear 205/60 R16 96 W XL
Wheel dimensions and material front 6.5 J x 16 inches, light-alloy
Wheel dimensions and material rear 6.5 J x 16 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (PS) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (PS) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,845
Max. permissible weight in kg 2,300
Permitted load in kg 530
Permitted axle load front/rear in kg 1,035/1,315
Luggage capacity min. (seats up or roof down) in l 375
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,500
Trailer load 12% (braked) in kg 1,500

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
Engine torque (Nm) at 1/min 300/1,350-4,000
Compression ratio : 1 11.0

Performance

Top speed in km/h 230
Acceleration 0–100 km/h in s 5.8
Top speed fully electric in km/h 140

Fuel consumption

Urban in l/100 km -
Extra-urban in l/100 km -
Combined in l/100 km 2.1
CO2 combined emissions in g/km 48
Electricity consumption, combined in kWh/100km 16.9
Tank capacity, approx. in l 40

Wheels

Tyre dimensions front 225/50 R17 98 Y XL
Tyre dimensions rear 225/50 R17 98 Y XL
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km up to xx
Growth capacity of lithium–ion battery in kWh 12.0
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h 2.6
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h 3.6

Electric engine

Electric engine power kW (PS) at 1/min 83 (113)/3,170
Electric Engine torque (Nm) at 1/min 265/100-2,500

Combined system power

Combined power kW (PS) 215 (292)
Combined torque Nm 420

Weight

Unladen weight EU in kg 1,810-1,745
Max. permissible weight in kg 2,245
Permitted load in kg 510-575
Permitted axle load front/rear in kg 1,115/1,230
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 275-285 (374-387)/5,500-6,500 - 5,800-6,500
Engine torque (Nm) at 1/min 500/1,800-5,000 - 1,900-5,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.4
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 10.0
Extra-urban in l/100 km 6.4
Combined in l/100 km 7.7
CO2 combined emissions in g/km 177
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/45 R18 95 Y XL
Tyre dimensions rear 255/40 R18 99 Y XL
Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (PS) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (PS) -
Combined torque Nm -
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW 330i Sedan:
Fuel consumption in l/100 km (combined): 7.3–6.4
CO2 emissions in g/km (combined): 166–147



Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

Read more

Fuel consumption and CO2 emissions.

  • BMW 330i Sedan:
    Fuel consumption in l/100 km (combined): 6.6
    CO2 emissions in g/km (combined): 150

    Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp.

    All technical data are indicative only and varies as per market and configuration. For more information, please check with your local dealer for all fuel consumption and CO2 emissions.
