TECHNICAL DATA FOR THE BMW 5 SERIES SEDAN.
| 1 | |
|---|---|
|
Fuel type |
bmw.web.technicaldata.fueltypeCode.p |
|
Power in kW (hp) |
190 (258) 2 |
|
Torque in Nm |
400 2 |
|
Transmission |
8-speed, automatic |
|
Drivetrain |
Rear-wheel drive |
| 1 | |
|---|---|
|
Cylinders |
4 |
|
Displacement in cm³ |
1,998 |
|
Nominal power in kW (hp)/1/min |
190 (258) |
|
Nominal torque in Nm/1/min |
400 |
|
(Nominal) power/30-minutes-power in kW (hp) |
8 (11) |
|---|---|
|
(Nominal) torque in Nm |
25 |
|
Acceleration 0–100 km/h in s |
6.2 |
|---|---|
|
Acceleration 0 - 100 km/h „1-Foot Rollout“ in s |
5.9 |
|
Top speed in km/h |
250 |
| 1 , 3 | |
|---|---|
|
Fuel consumption, combined WLTP in l/100 km |
7 |
|
CO2 emissions, combined WLTP in g/km |
159 |
| 4 | |
|---|---|
|
Battery capacity in kWh |
0.9 |
|
5,060 mm
|
|
|
1,900 mm
|
|
|
1,515 mm
|
|
|
Length in mm |
5,060 |
|
Width in mm |
1,900 |
|
Height in mm |
1,515 |
|
Width incl. mirrors (driver / passenger side) in mm |
2,156 |
|
Wheelbase in mm |
12.3 |
|
Vehicle curb weight in kg 5 |
1,700 |
|
Permissible gross weight in kg |
2,340 |
|
Payload in kg |
640 |
|
Roof rack mount without roof rails in kg |
75 |
|
Luggage capacity in l |
520 |
|
Tank capacity in l |
60 |
| 1 | |
|---|---|
|
Fuel type |
Petrol – 48 Volt Mild-Hybrid |
|
Power in kW (hp) |
153 (208) 2 |
|
Torque in Nm |
310 2 |
|
Transmission |
8-speed, automatic |
|
Drivetrain |
Rear-wheel drive |
| 1 | |
|---|---|
|
Cylinders |
4 |
|
Displacement in cm³ |
1,998 |
|
Nominal power in kW (hp)/1/min |
140 (190) / 4,400 - 6,500 |
|
Nominal torque in Nm/1/min |
310 / 1,500 - 4,000 |
|
(Nominal) power/30-minutes-power in kW (hp) |
13 (18)/10 (14) |
|---|---|
|
(Nominal) torque in Nm |
200 |
|
Acceleration 0–100 km/h in s |
7.5 |
|---|---|
|
Top speed in km/h |
230 |
| 1 , 3 | |
|---|---|
|
Fuel consumption, combined WLTP in l/100 km |
6.4–5.8 |
|
CO2 emissions, combined WLTP in g/km |
144-130 |
|
Pass-by noise in dB(A) |
67 |
|
Stationary noise level in dB(A) / 1/min |
73/3,750 |
| 4 | |
|---|---|
|
Battery capacity in kWh |
0.9 |
|
5,060 mm
|
|
|
1,900 mm
|
|
|
1,515 mm
|
|
|
Length in mm |
5,060 |
|
Width in mm |
1,900 |
|
Height in mm |
1,515 |
|
Width incl. mirrors (driver / passenger side) in mm |
2,156 (1,081/1,075) |
|
Wheelbase in mm |
2,995 |
|
Vehicle curb weight in kg 5 |
1,800 |
|
Permissible gross weight in kg |
2,335 |
|
Payload in kg |
610 |
|
Luggage capacity in l |
520 |
|
Tank capacity in l |
60 |
Fuel consumption and CO2 emissions.
BMW 520i sDrive: Fuel consumption, combined WLTP in l/100 km: 6,4–5,8; CO2 emissions, combined WLTP in g/km: 144–130
All technical data are indicative only and varies as per market and configuration. For more information, please check with your local dealer for all fuel consumption and CO2 emissions.
