    BMW 1 SERIES M135i xDRIVE: TECHNICAL DATA.

    Select model

    Weight

    Unladen weight EU in kg 1,600
    Max. permissible weight in kg 2.085
    Permitted load in kg 560
    Permitted axle load front/rear in kg 1,120/1,020
    Luggage capacity min. (seats up or roof down) in l 380
    Luggage capacity max. (seats down or roof up) in l 1,200
    Trailer load 8% (braked) in kg -
    Trailer load 12% (braked) in kg -
    Trailer load (unbraked) in kg -

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power* in kW (hp) at 1/min 225 (306)/5,000-6,250
    Engine torque (Nm) at 1/min 450/1,750-4,500
    Compression ratio : 1 9.5

    Performance

    Top speed in km/h 250
    Acceleration 0–100 km/h in s 4.8

    Fuel consumption

    Urban in l/100 km 9.1
    Extra-urban in l/100 km 6.5
    Combined in l/100 km 7.4
    CO2 combined emissions in g/km 170
    Tank capacity, approx. in l 50

    Wheels

    Tyre dimensions front 225/40 R18 92 Y XL
    Tyre dimensions rear 225/40 R18 92 Y XL
    Wheel dimensions and material front 8 J x 18 inches, light-alloy
    Wheel dimensions and material rear 8 J x 18 inches, light-alloy
    BMW wheels and tyres EU tyre label close-up

    BMW WHEELS & TYRES.

    We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

    FUEL CONSUMPTION AND CO2 EMISSIONS.

    BMW M135i xDrive:
    Fuel consumption in l/100 km (combined): 7.9–7.4
    CO2 emissions in g/km (combined): 178–168



    Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

    Read more
    ​

    Fuel consumption and CO2 emissions.

    • BMW M135i xDrive:
      Fuel consumption in l/100 km (combined): 7.4
      CO2 emissions in g/km (combined): 170

      Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

    ​
