TECHNICAL DATA FOR THE BMW M135 xDRIVE.
| 1 | |
|---|---|
Fuel type | Petrol |
Power in kW (hp) | 90 (122) |
Torque in Nm | 230 |
Transmission | 7-speed, automatic |
Drivetrain | Front-wheel drive |
| 1 | |
|---|---|
Cylinders | 3 |
Displacement in cm³ | 1,499 |
Nominal power in kW (hp)/1/min | 90 (122)/3,900–6,500 |
Nominal torque in Nm/1/min | 230/1,500–3,600 |
Acceleration 0–100 km/h in s | 9.8 |
|---|---|
Top speed in km/h | 210 |
| 1 , 2 | |
|---|---|
Fuel consumption, combined WLTP in l/100 km | 6.6–5.9 |
CO2 emissions, combined WLTP in g/km | 149-135 |
Energy consumption, combined WLTP in kWh/100 km | – |
4,361 mm | |
1,800 mm | |
1,459 mm | |
Length in mm | 4,361 |
Width in mm | 1,800 |
Height in mm | 1,459 |
Wheelbase in mm | 2,670 |
Vehicle curb weight in kg 3 | 1,465 |
Luggage capacity in l | 380–1,200 |
Tank capacity in l | 49 |
| 1 | |
|---|---|
Fuel type | Petrol |
Power in kW (hp) | 120 (163) |
Torque in Nm | 400 |
Transmission | 7 - automatic |
Drivetrain | All-wheel drive |
| 1 | |
|---|---|
Cylinders | 4 |
Displacement in cm³ | 1,995 |
Nominal power in kW (hp)/1/min | 120 (163)/3,750–4,000 |
Nominal torque in Nm/1/min | 400/1,500–2,500 |
(Nominal) power/30-minutes-power in kW (hp) | 15 (20)/– |
|---|---|
(Nominal) torque in Nm | 55 |
Acceleration 0–100 km/h in s | 7.9 |
|---|---|
Top speed in km/h | 222 |
| 1 , 2 | |
|---|---|
Fuel consumption, combined WLTP in l/100 km | 4.8–4.3 |
CO2 emissions, combined WLTP in g/km | 125–111 |
4,361 mm | |
1,800 mm | |
1,459 mm | |
Length in mm | 4,361 |
Width in mm | 1,800 |
Height in mm | 1,459 |
Width incl. mirrors (driver / passenger side) in mm | 1,800 |
Wheelbase in mm | 2,670 |
Vehicle curb weight in kg 3 | 1,570 |
Luggage capacity in l | 300–1,135 |
Tank capacity in l | 49 |
| 1 | |
|---|---|
Fuel type | Petrol |
Power in kW (hp) | 221 (300) |
Torque in Nm | 400 |
Transmission | 7-speed, automatic |
Drivetrain | All-wheel drive |
| 1 | |
|---|---|
Cylinders | 4 |
Displacement in cm³ | 1,998 |
Nominal power in kW (hp)/1/min | 221 (300) / 5,750–6,500 |
Nominal torque in Nm/1/min | 400/2,000–4,500 |
Acceleration 0–100 km/h in s | 4.9 |
|---|---|
Top speed in km/h | 250 |
| 1 , 2 | |
|---|---|
Fuel consumption, combined WLTP in l/100 km | 8.1- 7.6 |
CO2 emissions, combined WLTP in g/km | 184 - 173 |
4,361 mm | |
1,800 mm | |
1,459 mm | |
Length in mm | 4,361 |
Width in mm | 1,800 |
Height in mm | 1,459 |
Width incl. mirrors (driver / passenger side) in mm | 1,800 |
Wheelbase in mm | 2,670 |
Vehicle curb weight in kg 3 | 1,625 |
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg 4 | 750/75 |
Luggage capacity in l | 380–1,200 |
Tank capacity in l | 49 |
| 1 | |
|---|---|
Fuel type | Petrol |
Power in kW (hp) | 125 (170) |
Torque in Nm | 280 |
Transmission | 7 - automatic |
Drivetrain | Rear-wheel drive |
| 1 | |
|---|---|
Cylinders | 3 |
Displacement in cm³ | 1,499 |
Nominal power in kW (hp)/1/min | 125 (170) / 4,700 – 6,500 |
Nominal torque in Nm/1/min | 280 / 1,350 – 4,000 |
(Nominal) power/30-minutes-power in kW (hp) | 15 (20) / – |
|---|---|
(Nominal) torque in Nm | 55 |
Acceleration 0–100 km/h in s | 7.8 |
|---|---|
Top speed in km/h | 226 |
Electric top speed in km/h | – |
| 1 , 2 | |
|---|---|
Fuel consumption, combined WLTP in l/100 km | 6 – 5.3 |
CO2 emissions, combined WLTP in g/km | 135 – 120 |
Energy consumption, combined WLTP in kWh/100 km | – |
Electric range, WLTP in km | – |
Pass-by noise in dB(A) | – |
Stationary noise level in dB(A) / 1/min | – |
Battery capacity in kWh | 0.9 |
|---|---|
Added range after 10 minutes of high-power charging in km 5 | – |
Maximum charging power AC in kW | – |
Charging time AC 0–100% in h | – |
Maximum charging power DC in kW | – |
Charging time DC 10–80% in min | – |
4,361 mm | |
1,800 mm | |
1,459 mm | |
Length in mm | 4,361 |
Width in mm | 1,800 |
Height in mm | 1,459 |
Wheelbase in mm | 2,670 |
Vehicle curb weight in kg 3 | 1,500 |
Permissible gross weight in kg | – |
Payload in kg | – |
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg 4 | – |
Luggage capacity in l | 300 – 1,135 |
Tank capacity in l | 49 |
| 1 | |
|---|---|
Fuel type | Petrol |
Power in kW (hp) | 100–110 (136–150) |
Torque in Nm | 360 |
Transmission | 7 - automatic |
Drivetrain | All-wheel drive |
| 1 | |
|---|---|
Cylinders | 4 |
Displacement in cm³ | 1,995 |
Nominal power in kW (hp)/1/min | 100–110 (136–150)/3,250–4,000 |
Nominal torque in Nm/1/min | 360/1,500–2,500 |
Acceleration 0–100 km/h in s | 8.3–9.2 |
|---|---|
Top speed in km/h | 216–222 |
| 1 , 2 | |
|---|---|
Fuel consumption, combined WLTP in l/100 km | 5.2–4.6 |
CO2 emissions, combined WLTP in g/km | 136–122 |
4,361 mm | |
1,800 mm | |
1,459 mm | |
Length in mm | 4,361 |
Width in mm | 1,800 |
Height in mm | 1,459 |
Width incl. mirrors (driver / passenger side) in mm | 1,800 |
Wheelbase in mm | 2,670 |
Vehicle curb weight in kg 3 | 1,625 |
Luggage capacity in l | 380–1,200 |
Tank capacity in l | 49 |
Fuel consumption and CO2 emissions.
BMW M135 xDrive: Fuel consumption, combined WLTP in l/100 km: 8.1- 7.6; CO2 emissions, combined WLTP in g/km: 184 - 173
All technical data are indicative only and varies as per market and configuration. For more information, please check with your local dealer for all fuel consumption and CO2 emissions.
Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. In addition, NEDC values are deleted from the certificates of conformity as of 1 January 2023 by EC regulation 2022/195. For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp
Further information about fuel consumption and official model-specific CO2 emissions of new passenger cars can be found in the "Guideline for fuel consumption, CO2 emissions and electric power consumption for new passenger cars", available free of charge at all points of sale, at the Deutsche Automobil Treuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern-Scharnhausen, Germany, and under https://www.dat.de/co2/.
